Factory Direct 24 Inch DTF Printer with Automatic Powder Shaker Epson I3200 Printhead for T-Shirt Printing

The AGP DTF-T656 is a next-generation industrial 600mm Direct-to-Film printer designed for medium and large-scale garment decoration businesses. Equipped with 5 or 6 Epson I3200-A1 printheads, it delivers exceptional productivity, outstanding image quality, and stable long-term performance.

Rated 4.7/5 based on 581 customer reviews
Share:
Content

Product Overview

The AGP DTF-T656 is a next-generation industrial 600mm Direct-to-Film printer designed for medium and large-scale garment decoration businesses. Equipped with 5 or 6 Epson I3200-A1 printheads, it delivers exceptional productivity, outstanding image quality, and stable long-term performance.

Supporting both standard CMYK+White and Fluorescent/ORGB color configurations, the DTF-T656 enables users to create vibrant, premium-quality transfers suitable for fashion brands, sportswear manufacturers, promotional products, and print-on-demand businesses.


Product Specifications

Item Specification
Model DTF-T656
Printhead Epson I3200-A1
Printhead Quantity 5 Heads / 6 Heads
Print Width 600mm
Ink Configuration 3CMYK+2W / 2CMYK+2W+2Fluo / 2CMYK+2W+2ORGB
High Speed Mode 42㎡/h (5 Heads) / 14.9㎡/h (6 Heads Fluorescent)
High Precision Mode 34㎡/h / 11.6㎡/h
RIP Software RIIN, FlexiPrint, Cadlink, Maintop, NeoStampa
Feeding System Automatic Feeding & Take-up
Heating System Front & Rear Heating
Ink Supply Automatic Ink Supply
White Ink System Circulation + Stirring
Power 110V/220V
Working Temperature 20℃-30℃
Humidity 35%-65%


Product Features

1.

Powered by original Epson I3200-A1 industrial printheads for exceptional reliability.

2.

Available in both 5-head and 6-head configurations.

3.

600mm printing width fits all standard DTF PET films.

4.

Supports fluorescent color printing for premium garment decoration.

5.

Optional ORGB ink configuration expands color gamut.

6.

Industrial automatic feeding system ensures smooth media transport.

7.

Automatic take-up system enables unattended long-run printing.

8.

Integrated white ink circulation prevents nozzle clogging.

9.

White ink stirring maintains consistent ink quality.

10.

Front and rear heating improves ink curing efficiency.
